Diagnostic & Repair Resources:
https://cardiagn.com/2010-jeep-wrangler-jk-service-repair-manual-wiring-diagrams/
Tires: 32" 255/75R17
(Will fit -- just barely -- 33x12.50)
Wheels: 17"
5x5" Lug Pattern
Fluids:
Transmission: NSG370 (built by Mercedes)
The NSG370 does not use standard gear oil for lubrication
MOPAR Manual Transmission Lubricant or equivalent (meeting the re- quirements of Chrysler Material Standard MS-9224).
3.8L Engine Oil..............6 Quarts / 5.7 Liters........5w-20
.............................Chrysler MS-6395; if not API-SN
Brake Fluid..................Fill to Full Mark............DOT 3
Power Steering Reservoir.....Fill to Full Mark............ATF 4
3.8L Cooling System..........13 Quarts....................50/50 HOAT Antifreeze/Water Mix
NSG370 6-Speed Manual........1.6 Quarts / 1.5 Liters......Mopar Manual Trans Lubricant or Equivalent
NV241 Transfer Case..........2.2 Quarts / 2 Liters........ATF4
Dana 44 Front Axle...........2.7 pints / 1.3 Liters.......80w90
Dana 44 Rear Axle............4.75 Pints / 2.25 Liters.....80w90/75w140 summer towing
Filters:
Oil: Wix 51348
Air: Wix 49018
Tools Needed:
NSG370 Fluid Change: 1" M10 Bolt with two nuts (used to remove drain plug); 17mm wrench, 14mm Allen socket
NV241 Fluid Change: 10mm Allen socket, 18mm socket (remove cross member in the way)
Oil Change: 13mm socket
Front Brake (Pads):
13mm socket 26ft-lbs
21mm socket 100ft-lbs
11mm, 15mm wrenchs
Front Wheel Sensor -- 5mm Hex
Teraflex HD HD Chromoly Tie Rod Kit
OEM SKU 1853910
OEM SKU Ball Joint: 1344410; spare ordered to put in Jeep.
Factory Front Drive shaft u-joint: Non-serviceable w/o modifying yoke; Adams on order :)
Carbon Offroad Jeep JK Rubicon 2007-2018 4340 Chromoly Front Axle Kit Dana 44 CF155
1350 Series Spicer 5-7166X U-Joint; spare ordered to put in Jeep.
Front Axle Seal (verified by VIN online) Mopar p/n 5014852AB
Cross Reference:
Mopar 5014852AC
SKF 12579A
Spicer 54381
Timken / National 710863
Winch: Warn 10-S
Antirock Sway Bar:
Nuts are 1/2" (3/4" socket); uncertain if one side is RH and other LH thread.
Not JK specific; generic parts of a clutch:
Stock height specs (not sure if this is different for Rubicon):
Generic Torque Chart:
| Bolt Diameter | Standard | Metric |
| 1/8" | 5/16" | 8mm |
| 3/16" | 3/8" | 10mm |
| 1/4" | 7/16" | 11mm |
| 5/16" | 1/2" | 13mm |
| 3/8" | 9/16" | 14mm |
| 7/16" | 5/8" | 16mm |
| 1/2" | 3/4" | 19mm |
| 9/16" | 13/16" | 21mm |
| 7/8" | 22mm | |
| 5/8" | 15/16" | 24mm |
| 1" | 25mm | |
| 3/4" | 1-1/8" | 29mm |
| 1-1/4" | 32mm | |
| 7/8" | 1-5/16" | 34mm |
| 1-3/8" | 35mm | |
| 1" | 1-1/2" | 38 mm |
| 1-5/8" | 41mm | |
| 1-1/8" | 1-11/16" | 43mm |
| 1-3/4" | 45mm | |
| 1-1/4" | 1-7/8" | 48mm |
| 1-3/8" | 2" | 51mm |
| 1-1/2" | 2-1/4" | 57mm |
| 1-5/8" | 2-1/2" | 64mm |
| 1-3/4" | 2-5/8" | 67mm |
| 2-3/4" | 70mm | |
| 1-7/8" | 2-15/16" | 75mm |
| 3" | 76mm | |
| 2" | 3-1/8" | 80mm |
| 3-1/4" | 83mm | |
| 2-1/4" | 3-1/2" | 89mm |
| 3-3/4" | 95mm | |
| 2-1/2" | 3-7/8" | 99mm |
| 4" | 102mm | |
| 2-3/4" | 4-1/4" | 108mm |
| 4-1/2" | 114mm | |
| 3" | 4-5/8" | 118mm |
| 3-1/4" | 5" | 127mm |
| 3-1/2" | 5-3/8" | 137mm |
| 5-1/2" | 140mm | |
| 3-3/4" | 5-3/4" | 146mm |
| 6" | 152mm | |
| 6-1/2" | 165mm | |
| 7" | 178mm |
Dimensions for those making their own CO2 tire filling system:
Roof Rack: Barricade J116279
https://www.extremeterrain.com/barricade-removable-hard-top-roof-basket-0717-jk.html
Warn Zeon 10-S Winch
Parts diagram from Montana Jacks:
How to measure wheels:
Icom ID-5100A
Antenna Mount: Comet CP-5NMO; Max power 75W VHF, 50W UHF
Antenna: Diamond NR770HNMO;
3.0dB(2m); 5.5dB(70cm); Max power 200W
1/2 wavelength 2m radialless
2 x 5/8 wavelength 70cm phase element radialless
APRS APO3 automatic switch (turns on when voltage >= 13 volts, turns off 10 minutes after voltage drops) Hook for microphone: https://www.gigaparts.com/lido-products-lm-1201.html?utm_term=sku-zli-lm-1201 Lido Products LM-1201
Mahindra parts list: https://parts.mahindrausa.com/dealerview/illustration.aspx
Washer: Maytag Neptune MAH5500BWQ Dryer: Maytag Neptune _________
